| Warm-up time: |
14 seconds (SP models) |
|
|
|
71 seconds (Z models) |
|
| Time to complete the first page: |
4,6/4,6/4,3/4/2,9/2,9 másodperc |
|
| Continuous print speed: |
25/30/35/40/50/60 lap/perc |
|
| Memory: |
2 GB |
|
| Hard disc: |
320 GB |
|
| Dimensions (Sz x Mé x Ma): |
With ARDF unit: |
587 x 680 x 913 mm |
|
|
|
with SPDF: |
587 x 680 x 963 mm |
|
| Weight: |
With ARDF unit: |
68,5 kg |
|
|
|
with SPDF: |
74 kg |
|
| Power supply: |
220 – 240 V, 50/60 Hz |
|
COPY
|
|
| Copy procedure: |
(Iker) laser scanning and electro-photographic printing |
|
| Multi-copy copying: |
Up to 999 copies |
|
| Resolution: |
600 dpi |
|
| Zoom: |
Between 25% and 400% in 1% increments |
|
PRINTER
|
|
| Page-turning language: |
By default: |
PCL5e, PCL6(XL), PDF direct printing |
|
|
|
Options: |
XPS, Adobe® PostScript® 3™, IPDS |
|
| Print resolution: |
Maximum: |
1 200 x 1 200 dpi |
|
| Interfaces: |
By default: |
USB 2.0, SD foglalat, Ethernet 10 base-T/100 base-TX, Ethernet 1000 Base-T |
|
|
|
Options: |
Bi-directional IEEE 1284, Wireless LAN (IEEE 802.11a/b/g/n), Bluetooth, Additional NIC (2nd port) |
|
| Network Protocolls: |
TCP/IP (IP v4, IP v6), Option (IPX/SPX) |
|
| Windows® environments: |
Windows® XP, Windows® Vista, Windows® 8.1, Windows® Server 2003, Windows® Server 2012, Windows® Server 2012R2 |
|
| Mac OS environments: |
Macintosh OS X Native v10.6 or newer |
|
| UNIX envroments: |
UNIX Sun® Solaris, HP-UX, SCO OpenServer, RedHat® Linux, IBM® AIX |
|
| SAP® R/3® environments: |
SAP® R/3® |
|
| Other supported environments: |
NDPS Gateway, AS/400® OS/400 Host Print Transform, IBM iSeries |
|
SCANNER
|
|
| Scanning speed: |
ARDF (automatic page translator document feeder): |
Max. 80 originals/min |
|
|
|
SPDF: |
Max. 110 (simplex)/180 (duplex) originals/min |
|
| Resolution: |
Maximum: |
300 dpi |
|
| Original size: |
A3, A4, A5, B4, B5, B6 |
|
| The driver programs supplied in the package: |
Network TWAIN |
|
| Scan: |
E-mail, Folder, USB, SD-card |
|
FAX
|
|
| Phone line: |
PSTN, PBX |
|
| Compatibility: |
ITU-T (CCITT) G3 |
|
| Resolution: |
8 x 3,85 line/mm, 200 x 100 dpi |
|
|
|
8 x 7,7 line/mm, 200 x 200 dpi |
|
|
|
Options: |
8 x 15,4 line/mm, 400 x 400 dpi, 16 x 15,4 line/mm, 400 x 400 dpi |
|
| Transmission speed: |
G3: |
2 seconds |
|
| Modem speed: |
Maximum: |
33,6 Kb/s |
|
| Memory capacity: |
Maximum: |
60 MB |
|
PAPER MANAGEMENT
|
|
| Recommended paper size: |
A3, A4, A5, A6, B4, B5, B6 |
|
| Input paper capacity: |
Maximum: |
4700 sheet |
|
| Output paper capacity: |
Maximum: |
3625 sheet |
|
| Paper weight: |
Standard paper trays: |
60 – 300 g/m² |
|
|
|
Hand dispenser tray: |
52 – 300 g/m² |
|
|
|
Duplex unit: |
52 – 256 g/m² |
|
ENVIRONMENT
|
|
| Energy consumption: |
Maximum: |
1,78 kW |
|
|
|
Standby mode: |
54,6 W (25/30/35 ppm), 81,4 W (40/50/60 ppm) |
|
|
|
Standby status: |
0,49 W (25/30/35 ppm), 0,51 W (40/50/60 ppm) |
|
SOFTWARE
|
|
| By default: |
Web Image Monitor |
|
| Options: |
GlobalScan NX, Streamline NX, Card Authentication Package, Enhanced Locked Print, Unicode Font Package SAP-hez |
|
OPTION
|
|
- 1 550-sheet paper tray
- 2 550-sheet paper feeders
- 2000 sheet high capacity dispenser
- 1,500 sheet high capacity dispenser
- Papírátvezető egység
- 1000 sheet finisher
- 3 000 sheet finiser
- Internal finisher
- Internal finisher without staple
- 1 000 sheet booklet maker finisher
- 2 000 sheet booklet maker finisher
- Punching kit
- Internal moving tray
- Single compartment tray
- Side tray
- Additional wheeled frame
- Low machine table
- Bidirectional IEEE 1284
- USB Server for Second Network Interface
- Bluetooth
- Netware
- PostScript3
- IPDS unit
- Browser unit
- Counting interface
- File Format Converter
- Key counter bracket
- Card reader holder
- Copy Data Security Unit
- Fax contact unit
- Fax marker
- 2. Super G3 port
- Fax memory
- Fax opcion
- Wireless LAN (IEEE 802.11a/g/n)
- OCR unit
- Built-in smart card reader
- XPS direct printing
- Extended security HDD
|
|
| The internal finisher is not an option for 60 ppm models. |
|
| The stapleless finisher is not an option for the 40/50/60 ppm models. |
|
| The 2 000 and 3 000-sheet finisher is not an option for the 25/30/35 ppm models. |
|
